Dump semi Trailer
Rear/Tipping dump trailer
Overall Dimension	1300026002800mm or Customized
Curb Weight	10,000 kg
Loading Capacity	100,000 kg
Main Beam Spec.	Carbon Steel, Upper 18mm, bottom 20mm, middle plate 8+8 mm
Side Frame	Channel Steel
Cross Brace	Channel Steel/Bending Steel
Bucket	Carbon Steel, Bottom 9mm, Side 6mm
Suspension	3 Mechanical Suspensions + 3 Air Suspensions
Leaf Spring	13-layers leaf spring 120mm13mm10pcs
Axle Spec.	16T * 6pcs
King Pin	2"(50mm)or3.5"(90mm)
Tire	12.00R20
Brake Chamber	12sets
Landing Gear	28T*2
Accessories	1 Standard Tool Box
Electric System	24V, One Set 6-core Standard Cable
Light	Tail lamp with turn signal,brake light & reflector,side lamp etc
Painting	Sand blasting, prime coating, surface painting,color optional, wax polishing
Packing	Bulk Cargo Vessel, Ro-ro Shipment or Optional

Heavy Duty Hydraulic Rollover Dump Trailer 40-120T Air Suspension 1

Heavy Duty Hydraulic Rollover Dump Trailer 40-120T Air Suspension 2

Frequently Asked Questions

Does your company have your own factory?

Yes, we have our own factory in Shandong, China, specializing in trailer manufacturing for several years. Our facility is well-known for producing various types of trailers.

What is your minimum order quantity?

One unit.

Can you satisfy my special requirements?

Absolutely! We can customize trailers according to your specific requirements.

What logistics methods do you offer for transportation?

We provide multiple transportation options:

Primary method: Shipping by container or ro-ro/bulk vessel
For neighboring countries: Road or rail transport
For urgent spare parts: Express shipping via DHL, TNT, UPS or FEDEX

Do you offer any additional services?

Our comprehensive services include competitive pricing, shipping and packaging solutions, cargo hold booking assistance, and parts procurement support.

Send your inquiry to begin our partnership. Our expert team is ready to assist you throughout the process.

Email: juyuan@aotongtrailer.com

Phone: +86 139 6962 7783

With over 30 years of trailer manufacturing experience, we've earned your trust through quality and reliability.

Les étiquettes:

dump semi trailer,

DéTAILS DES PRODUITS

Produits

Semi-remorque à basse altitude

semi-remorque de conteneur

Remorque de mur latéral semi

Semi-remorque pour véhicule de transport

Semi-remorque à déchargement/déplacement

Partie de véhicule à roues

Barrière Semi Trailer

Semi-remorque pour le transport des animaux

de bateau-citerne remorque semi

Trailers agricoles et autres trailers entiers

Le camion à ordures Howo

tête de tracteur

Trailer spécial

Pièces détachées de remorques

Nouveaux véhicules d'énergie

Véhicules spéciaux

Heavy Duty Hydraulic Rollover Dump Trailer 40-120T Air Suspension

Nombre De Pièces:	1 unité
Emballage Standard:	Norme d'exportation
Période De Livraison:	25 jours
Méthode De Paiement:	T / t

Informations détaillées

Description du produit

Informations détaillées

Lieu d'origine

Chine

Nom de marque

AOTONG

Certification

ISO,CCC

Suspension:

Suspension mécanique ou aérienne

Spécifications des pneus:

12R22.5

Poutre principale:

Lourde je fais la poutre.

Épingle:

Type de boulon 2 '' / 3,5 ''

Système de freinage:

Chambre à air double, vanne de frein, réservoirs d'air 45L; ABS en option

Électrique:

Lumière LED, 7 façons, 24V

Peinture:

Spanting et propre rouille, 1 couche de peinture de premier ordre, 2 couches de peinture de finition

Quantité de commande min:

1 unité

Détails d'emballage:

Norme d'exportation

Délai de livraison:

25 jours

Conditions de paiement:

T / t

Mettre en évidence

heavy duty hydraulic dump trailer

air suspension rollover trailer

120T tipping semi trailer
